84
Setting the con-
tact pressure
Adjusting the
brake
CAUTION! Risk of injury from wire electrode emerging at speed. Keep the weld-
ing torch away from face and body when pressing the feeder inching / inch for-
ward button.
5
6
1
1
NOTE! Set the contact pressure in
such a way that the wire electrode
is not deformed but nevertheless
ensures that the wire is transport-
ed properly.
Contact pressure stand-
ard values
Semi-cylindrical
rolls
Trapeze rolls Plastic rolls
Aluminium 1.5 - 3.5 - 4.5
Steel 3 - 4 1.5 -
CrNi 3 - 4 1.5 -
NOTE! After releasing the torch trigger the wirespool should stop unreeling. Ad-
just brake if necessary.
