MIG/MAG standard manual welding
General The MIG/MAG standard manual welding process is a MIG/MAG welding process with no
Synergic function.
Changing one parameter does not result in any automatic adjustments to the other param-
eters. All of the variable parameters must therefore be adjusted individually, as dictated by
the welding process in question.
The inputs required for MIG/MAG standard manual welding are described by reference to
the "Comfort" control panel.
Available parame-
ters
In MIG/MAG standard manual welding, the following parameters are available:
MIG/MAG stand-
ard manual weld-
ing
Press the Process button to select the MIG/MAG standard manual welding process
Press the Material button to select the filler metal and shielding gas used
The assignment of SP1 and SP2 depends on the welding database used for the power
source.
Press the Wire diameter button to select the diameter of the wire electrode
The assignment of SP depends on the welding database used for the power source.
Press the Mode button to select the desired MIG/MAG mode:
2-step mode
4-step mode
Special 4-step mode (aluminium welding start-up)
Spot welding
In MIG/MAG standard manual welding, special 4-step mode corresponds to conven-
tional 4-step mode.
The settings for the parameters for Spot welding mode are described in the Setup
menu.
Press the Parameter selection button and select the wire feed speed parameter
Use the adjusting dial to set the desired value for the wire feed speed
Press the Parameter selection button and select the welding voltage parameter
Use the adjusting dial to set the desired value for the welding voltage
The parameter value is displayed in the digital display located above it.
Wire feed speed
0.5 m/min (19.69 ipm) - maximum wire feed speed
e.g. 22.0 m/min (866.14 ipm)
Welding voltage
TPS 3200 / 4000 / 5000: 10.0 - 40.0 V
TPS 2700: 10.0 - 34.0 V
Dynamic correction
for influencing the short-circuiting dynamic at the instant of droplet transfer
Welding current
only the actual value is displayed
NOTE! Parameters that have been set on a system component control panel
(e.g. wire feed unit or remote control) might not be able to be changed on the
power source control panel.
