As long as the power source is switched on, the corrected parameter values remain saved.
After the power source has been switched on again, the parameters are reset to the per-
manently settable values.
"Minimum" and "maximum" are used for setting ranges that differ according to power
source, wire-feed unit, welding program, etc.
PcH
Power correction High - Correction boundary (high) for the welding power
Unit % (of permanently settable parameter P - power correction)
Setting range 0 - 20
Factory setting 0
NOTE! The maximum amount by which parameter P can be increased is the val-
ue set for PcL.
PcL
Power correction Low - Correction boundary (low) for the welding power
Unit % (of permanently settable parameter P - power correction)
Setting range 0 - 20
Factory setting 0
NOTE! The maximum amount by which parameter P can be decreased is the val-
ue set for PcL.
AL.c
Arc length correction (up or down)
Unit % (of permanently settable parameter AL.1)
Setting range 0 - 30
Factory setting 0
NOTE! The maximum amount by which parameter AL.1 can be increased or de-
creased is the value specified for AL.c.
JSL
Job Slope - defines the time between the job that is currently selected and the next job
Unit s
Setting range OFF or 0.1 - 9.9
Factory setting OFF
