Supply voltages
Supply voltages
IMPORTANT! The voltages listed above may only be used to supply a robot control output
card. The output cards are usually supplied by an internal power supply on the robot con-
troller. For this reason, pins 5 to 8 are usually unoccupied.
WARNING! An electric shock can be fatal. Never connect the robot controller
supply to the power supply for the KD 7000 or the power source.
Plug X3/pin 5 ("+ 24 V TIG") 24 V
Plug X3/pin 6 ("GND TIG") GND (power supply)
Plug X3/pin 7 ("+ 15 V TIG") 15 V
Plug X3/pin 8 ("- 15 V TIG") - 15 V
