51
EN
Technical data
KD 7000
Mains voltage 200 - 240 V AC
Nominal current 1,2 A
Mains fuse protection slow-blow 2 A
Types of wirespool all standard
Max. permitted wirespool weight 16 kg (35.27 lb.)
Wirespool diameter 300 mm (11.81 in.)
Wire speed 0,2 - max. m/min
7.87 - max. ipm
Wire drive 4-roller drive
Wire diameter 0,8 - 1,6 mm
0.03 - .0.06 in.
Wirespool diameter max. 300 mm
max. 11.81 in.
Degree of protection IP 23
Dimensions l x w x h 640 / 260 / 430 mm
25.2 / 10.2 / 16.9 in.
Weight 17 kg
37.4 Ib.
EMC device class (in accordance with EN/IEC 60974-10) A
Mains connection Restrictions possible
