Setup menu
General remarks Select the characteristic type in the Setup menu depending on either the battery
to be charged or the requirement as specified in the accompanying characteristic
data sheet.
Accessing the
Setup menu
Please note:
Do not connect the charging lead to the battery.
A characteristic type cannot be selected when the charging plug is connected.
1
Connect the mains cable to the charger and plug into the mains.
2
Charger is on standby - ready indicator is lit.
3
Press and hold the Start/Stop button for approx. 10 seconds to call up the
Setup menu.
4
Ready indicator goes out. The charger is in Setup mode. The display also
shows the selected characteristic type.
Selecting the
characteristic
type
1
Press the Start/Stop button to select the characteristic type according to
the enclosed characteristic data sheet.
2
If there is no further selection within 10 seconds, the selected characteristic
type is saved.
Please note:
Do not connect a battery during these 10 seconds.
Continue as described in the section "Charging the battery".
3
Ready indicator lights up. Once the new characteristic type has been selec-
ted, the charger is automatically ready for the next charging sequence.
22
