Fronius Symo 10.0-3-M Installation Instructions

Notes regarding software updates
Notes regarding
software up-
dates
+
3
5 4 4
1
2
2
If the inverter is supplied with a USB
flash drive, the inverter software must
be updated as soon as the inverter has
been commissioned:
1
Plug the USB flash drive into the
data communication area of the in-
verter
2
Open the Setup menu
3
Select the "USB" menu item
4
Select "Software Update"
5
Update the software
43
EN

Fronius Symo 10.0-3-M Specifications

General

Max. output current	16.7 A
Max. input voltage	1000 V
MPP voltage range	200 - 800 V
Number of MPP trackers	2
Protection class	IP 65
AC voltage range	150 - 280 V
Frequency	50 / 60 Hz
THD	< 3 %
AC Nominal Power	10000 W
MPPT Voltage Range	200 - 800 V
AC Frequency	50 / 60 Hz
AC nominal output	10000 W
Max. apparent AC power	10000 VA
DC input voltage range	200-1000 V
Operating Temperature	-25°C to +60°C
Dimensions (W x H x D)	725 x 510 x 225 mm
AC nominal voltage	3 x 230 / 400 V
