Fronius VarioStar 2500 - Wire Spool Installation; Safety During Spool Installation; Installing the Wire Spool; Installing the Basket-Type Spool

15
EN
Inserting the
wirespool
Inserting the wirespool/inserting the basket-type spool
Inserting the
basket-type
spool
Working with basket-type spools requires a basket spool adapter.
NOTE! If working with basket spools, only use a basket spool adapter provided
by the manufacturer.
CAUTION! Risk of injury from springiness of spooled welding wire. While
inserting the wirespool/basket-type spool, hold the end of the welding wire
firmly to avoid injuries caused by the wire springing back.
CAUTION! Risk of injury from falling spool. Place basket-type spool on the
adapter provided in such a way that the bars on the spool are inside the
adapter guideways.
CAUTION! Risk of injury from falling spool. Make sure that the wirespool or
basket spool adapter with spool is fitted securely to the wirespool holder.
1
1
2
4
3
Safety
1
3
2
1
2
1
2
2
1
