Fronius Wattpilot Go 11 J User Manual

Technical data
Technical data
Fronius Wattpilot Go 11 J Go 22 J Home 11 J
Max. charging power 11 kW 22 kW 11 kW
Mains supply types TT / TN / IT
Mains connection CEE plug, red,
16 A, 5‑pin
incl. neutral con-
ductor
CEE plug, red,
32 A, 5‑pin
incl. neutral con-
ductor
5‑pin cable without
plug
Optional adapter set CEE plug, red, 32 A
(3-phase fused)
CEE plug, blue,
16 A camping plug
(1‑phase)
Earthed plug, 16 A
(household socket)
CEE plug, red, 16 A
(3-phase)
CEE plug, blue,
16 A camping plug
(1‑phase)
Earthed plug, 16 A
(household socket)
-
Nominal voltage 230 V (1‑phase) / 400 V (3‑phase)
Nominal current (configurable) 6 ‑ 16 A
1‑phase or
3‑phase
6 ‑ 32 A
1‑phase or
3‑phase
6 ‑ 16 A
1‑phase or
3‑phase
Grid frequency 50 Hz
Power consumption 1.9 W (LED dark), 4.2 W (LED bright)
Charging socket Type 2 infrastructure socket with
mechanical lock
Residual current device 30 mA
AC
/6 mA
DC
Supply line cable cross-section
Min. 2.5 mm
2
Min. 6 mm
2
Min. 2.5 mm
2
RFID (radio frequency identification) 13.56 MHz
WLAN IEEE 802.11b/g/n | 2.4 GHz
channel 1-13 (2412 - 2472 MHz) | max. 19.29 dBm
Protection class IP 54 (IP 44 with Type 2 cable plugged in)
Impact resistance IK08
Dimensions (width x height x depth) 14.6 x 25.1 x 9.6 cm
Weight 1.6 kg 1.9 kg 1.9 kg
Environmental conditions
Use Indoors and outdoors
No direct sunlight
Installation type Suspended
Ambient temperature -25 to +40 °C
Storage temperature -40 to +85 °C
Average ambient temperature over 24
hours
Max. 35 °C
51
EN
