Specifications 175
ELECTRONICS MODULE
Color: Blue module case, white front panel and gray bezel
Size: 17.4"W x 6.5"H x 14.6"D (44.2 x 16.5 x 37.1 cm).
Weight: 17 lbs.(7.7 kg).
PRINTER, INTERNAL
Type: High speed line thermal printer
Paper width: 4.41" (112 mm)
Print speed: 80 mm/ s
PRINTER, EXTERNAL (PRINTER NOT PROVIDED)
Port: 25 pin D, female
Type: HP compatible, Epson Stylus series
Language: HPCL3 and ESC-P/2
TEST CHAMBER
Type: FONIX FC 7020
Test Area: 7"x 7.5"x 1.5 deep (17.8 x 19.1 x 3.8cm).
Internal Acoustic SPL at test point will change less than 3 dB above
Reflections: 1 kHz, when lid is raised (w/o feedback compensation).
Ambient Noise Isolation: 45 dB at 1 kHz (allows THD measurement to within 3% at 60 dB
source level and a 60 dB ambient).
Color: Gray with black trim. Black and white test area.
Size: 13.5”W x 18"H x 11.5"D (34.3 x 45.7 x 29.2cm).
Weight: 36 lbs. (16.3 kg).
SHIPPING, INTERNATIONAL
Total Shipping Weight with Quik-Probe Option: 97 lbs. (45 kg)
Total Shipping Weight without Quik-Probe Option: 77 lbs. (35 kg)
STANDARD ACCESSORIES
FONIX M1950E Low Noise 14 mm diameter, pressure type Electret
Microphone: with add-only memory chip. 149 dB maximum SPL.
Microphone Adapter: (044-1006-01) 14mm to 1" (25 mm).
HA-1 Coupler: (044-1003-03) Dimensions per requirements of ANSI S3.7-1995
for testing all-in-the-ear aids and earmolds.
HA-2 Coupler: (044-1001-04) Dimensions per requirements of ANSI S3.7-1995
for testing ear level, eyeglass and body aids.
