2-3
ITEM PART # COMPONENT
1 Gear Motor, Basket Lift
807-0107 120VAC
807-0108 240VAC
2 807-0124 Bushing, Plastic
3 807-0240 Microswitch
4 826-1680 Clamp, Plastic Wire (Pkg. of 8)
5 826-1358 Nut, 6-32 Hex (Pkg. of 25)
6 809-0050 Nut, 2-32 Hex
7 809-0063 Nut, Jam ⅜-16 Hex
8 809-0076 Nut, ¼-20 x ¾ Expansion
9 809-0082 Ring, Truarc Retaining
10 809-0097 Screw, 6-32 X 1-inch Slotted Truss Head
11 809-0113 Screw, 2-32 X 1½-inch Slotted Truss Head
12 809-0127 Screw, ¼-20 X ½-inch Slotted Round Head
13 826-1370 Screw, ¼-20 X 1¼-inch Slotted Round Head (Pkg. of 10)
14 809-0155 Leveling Screw
15 809-0196 Washer, ⅜-inch Steel Flat
16 826-1381 Washer, Nylon (Package of 10 each 809-0203)
17 809-0360 Screw, 2-32 X ⅜-inch Slotted Hex Washer Head
18 826-1374 Screw, 10 X ½-inch Hex Washer Head (Pkg. of 25)
19 809-0480
Setscrew, ¼-28 X
5
⁄
8-
inch Hex Socket Head
20 810-0045 Bushing, Plastic
21 810-0052 Bellcrank and Cam
22 810-0170 Pin, Connecting
23 810-0172
Plug,
5
⁄
8-
inch Hole S/S
24 810-0192 Rod, Basket Lift
25 810-0220 Spacer, Tubular
26 812-0138 Insulation, Paper (Fishpaper)
27 813-0035 Bushing, Bronze
28 823-1419 Box, Electrical Wiring
29 900-4110 Angle, Bearing Support
30 910-0119 Cover, Electrical Wiring Box
31 910-3177 Panel, Stainless Steel Rear Access (for mild steel, use 900-3177)
32 910-3783 Cover, Stainless Steel Rear Cabinet (for mild steel, use 900-3783)
33 910-9361 Housing, Basket Lift Stainless Steel (for mild steel, use 900-9361
34 920-3233 Plate, Basket Lift Motor Mounting
35 920-6076 Link, Basket Lift
36 823-06931 Basket Lift Arm, Left
37 823-06932 Basket Lift Arm, Right
NOTE: See Page 2-20 for Roller Bracket Assembly.
