Frymaster 45 Series - Door Assembly

2-25
DOOR ASSEMBLY
3
1
4
7
6
2
5
5
ITEM PART # COMPONENT
806-8320
Door Assembly Complete, Enameled Steel (does not include Items 3 and 5)
806-6405SP
Door Assembly Complete, Stainless Steel (does not include Items 3 and 5)
1 106-0554SP Door Pin Assembly
2 826-1343 Spring, Door Pin
3 810-1422
Handle, Door, Wireform, Stainless Steel (must be ordered separately)
4 826-1379 Screw, #10 x ½” Phillips Head, Zinc Plated
5 810-1508
Hinge, Door, Universal (must be ordered separately)
6 824-0616SP Panel, Door, Outer
7 900-4807 Liner, Door
* 810-1105 Magnet, Door
* Not illustrated.
