Frymaster 45 Series - Modular Basket Lift

2-4
Modular Basket Lift
NOTES: 1. Assemblies 106-1807SP (100-120V) and 106-1810SP (208-250V) do not include Items 8, 16, 24, 25, and 26. These items must be ordered separately. 2. For 100-120V units, each individual resistor (807-2661) may be replaced or the entire reistor assembly (806-8530SP) may be replaced. 3. For 208-250V units, the entire resistor assembly (106-2771 or 806-9185) must be replaced. 4. Wiring has been omitted for clarity.
24
14
100-120V Configuration 208-250V Configuration
2114117
12105
20135
26
8
17
25
16
3 13
4 10 12 18
2314
14 22
1
6
19 1592
5
(After 10/02)
(Before 11/02)
