2-17
ITEM PART # COMPONENT
Complete Shield Assemblies
806-4774SP 120V, 50/60 Hz without Melt Cycle Timer (Non-CE)
806-4776SP 240V, 50/60 Hz without Melt Cycle Timer (Non-CE)
806-4772SP 120V, 50/60 Hz with Melt Cycle Timer (Non-CE)
806-4777SP 240V, 50/60 Hz with Melt Cycle Timer (Non-CE)
806-6630SP 230V, 50 Hz without Melt Cycle Timer (CE)
806-6632SP 230V, 50 Hz with Melt Cycle Timer (CE)
Components
1 900-4340 Shield, Component
2 807-0066 Block, Terminal, 20-Pin
3 809-0097 Screw, 6-32 x 1-inch Slotted Truss Head
4 826-1358 Nut, 6-32 Hex (Pkg. of 25)
5 816-0217 Paper, Insulating
6 810-1164 Terminal Block, 6-Position
7 810-1168 Terminal Block, 8-Position
8 826-1359 Screw, 4-40 X ¾-inch Slotted Round Head (Pkg. of 25)
9 826-1366 Nut, 4-40 Hex Keps (Pkg. of 25)
10 807-0800 Transformer, 100-120V Primary/24V Secondary 50/60 Hz 50VA
11 Transformer, 208-240V Primary/24V Secondary 50/60 Hz
807-0680 20VA without fuse
807-2180 50 VA with fuse
* 807-1597 Fuse, 3-Amp Slow-Blow (for use w/transformer 807-2180)
12 807-1999 Transformer, 208-240V Primary/12V and 24V Secondary Dual Voltage
13 826-1374 Screw, #10 x ½-inch Hex Washer Head (Pkg of 25)
14 810-0045 Bushing, Heyco (fits 1.25-inch hole)
15 807-2469 Bushing, Heyco (fits ⅞-inch (.875-inch) hole)
16 826-1546 Kit, Melt Cycle Timer (Items 17, 18, and 19) replaces electromechanical timer
17 806-9613 PC Board Assembly, Melt Cycle Timer (50 and 60 Hz)
18 900-8741 Bracket, Melt Cycle Timer
19 809-0580 Standoff, PC Board
20 807-0156 Plug, 9-Pin
* Not illustrated.
