ITEM PART # COMPONENT
1 Pump Motor
826-1712 100-120 VAC 50/60Hz (includes gasket 816-0093)
826-1756 208 VAC 50/60 Hz (includes gasket 816-0093)
826-1270 230-250 VAC 50/60 Hz (includes gasket 816-0093)
* 806-6728SP Pump Motor Wiring Assembly (used with above motor kits)
2 826-1264 Pump, 4 GPM (15 LPM) (includes gasket 816-0093 and mounting screws)
3 813-0265 Nipple, ½-inch x 2 ½-inch
4 813-0062 Elbow, ½-inch x 90º
5 813-0368 Nipple, ½-inch x 16-inch
6 813-0156 Pipe Plug, ½-inch
7 813-0003 Tee, ½-inch
8 810-1057 Flexline, 13-inch Oil Return (has female ends)
* 810-1668 Adapter, Male (used with Item 8; two required)
9 813-0275 Nipple, ½-inch x 9-inch
10 810-0278 Valve, ½-inch Ball
11 902-0883 Handle, Valve
12 813-0165 Elbow, ½-inch x 90º Street
13 813-0022 Nipple, ½-inch Close
14 823-1356 Disconnect Fitting
15 826-1392 O-Ring (pkg of 5)
16 816-0102 Grommet, Oil Diverter
17 900-1472 Diverter, Oil
18 910-1627 Bracket, Male Disconnect Support
19 813-0330 Bushing, ½-inch NPT to ½-inch Tube
20 806-4694SP Contactor Block Assembly
* 813-0117 Nipple, ½-inch x 3½-inch
* 807-1600 Thermal Switch, 100-120V Baldor Motors
* 807-1601 Thermal Switch, 200-250V Baldor Motors
* 807-1598 Thermal Switch, 100-120V Magnatek Motors
* 807-1599 Thermal Switch, 200-250V Magnatek Motors
* 807-2016 Wiring Harness, Controller to Filter
* 807-1408 Heater Strip, 120VAC 50W, 70-inch
* 807-2050 Heater Strip, 250VAC 90W, 70-inch
* 811-0746 Tape, Aluminum (2-inch x 50-yard (46m) roll)
* Not illustrated
