Frymaster FilterQuick Version 2 - Using Tech Modes; Error Log Codes

2-5
2.2.3 Using Tech Modes
The FilterQuick™ controller has a Tech Mode menu accessed with Code 3000, which allows
clearing of E-log, password reset, lane count, hold mode and high limit test.
Left Display Right Display Action
OFF OFF
Start with the far LEFT controller. Press  until the controller
scrolls Info Mode, changing to Main and then PRODUCT SETUP.
Product Setup Blank
Press  to scroll to Tech Mode. Press .
Tech Mode Enter Code
Enter 3000
Clear E-Log Blank
Press  to clear error codes. Press . Clears captured error codes.
Clear passwords Blank
Press  to clear passwords. Press .
Lane count 2
Press  to change Lane Count. Press .
HOLD MODE STANDARD
Press  to toggle to LANE. Press . If this function is set to
Standard, the hold timer runs the countdown in the background. If
it is set to Lane, the hold timer countdown is visible with the time
remaining.
Hi limit test* Blank
Press to initiate Hi-Limit test. 
Hi limit test* YES NO
Press to start; press  to decline. Press .*
Exit Exit
Press Exit/Scan twice.
OFF OFF
*This test will ruin the oil and should only be conducted by a technician.
2.2.4 Error Log Codes
Code ERROR MESSAGE EXPLANATION
E03 ERROR TEMP PROBE FAILURE Temp probe reading out of range
E04 HI 2 BAD High limit reading is out of range.
E05 HOT HI 1 High limit temperature is past more than 410°F
(210°C), or in CE countries, 395°F (202°C)
E06 HEATING FAILURE A component has failed such as controller, interface
board, contactor, gas valve, ignition module or
open-high limit.
E07 ERROR MIB SOFTWARE Internal MIB software error
E08 ERROR ATO BOARD MIB detects ATO board connection lost; ATO board
failure
E09 ERROR PUMP NOT FILLING Dirty pad and it needs changed or it was bypassed;
filter pump problem
E10 ERROR DRAIN VALVE NOT OPEN Drain valve was trying to open and confirmation is
missing
E11 ERROR DRAIN VALVE NOT CLOSED Drain valve was trying to close and confirmation is
missing
E12 ERROR RETURN VALVE NOT OPEN Return valve was trying to open and confirmation is
missing
E13 ERROR RETURN VALVE NOT
CLOSED
Return valve was trying to close and confirmation is
missing
