Frymaster LOV BIELA14 - Drain Valves and Associated Parts

2-4
2.3.2 Drain Valves and Associated Parts
2.3.2.1 Linear Actuator Drain Valves
ITEM PART # COMPONENT
1 809-0540 Nut, ½-13 2-Way Hex Lock
2 900-2936 Retainer, Nut Drain Valve
3 232-5701 Handle, Drain Valve FV or DV Right
4 231-5701 Handle, Drain Valve DV Left
5 824-2048 Mount, Electric Drain Actuator Right
6 824-2047 Mount, Electric Drain Actuator Left
7 222-5962 Bracket, Drain to Valve LOV™ Electric
8 816-0544 O-Ring, Round Drain Seal
9 823-7231 Valve, 1¼-inch Drain LOV™ Electric Right
10 823-7230 Valve, 1¼-inch Drain LOV™ Electric Left
2.3.2.2 Rotary Actuator Drain Valves
ITEM PART # COMPONENT
1 810-3755 Valve, 1¼-inch NPT Rotary Actuator
