2-17
2.4.5.8 M3000, MIB, AIF and ATO Wiring Harnesses
ITEM PART # COMPONENT
* 807-4546 Computer Communication (used from Computer to Computer)
* 807-4547 AIF Communication/Power (used from MIB to AIF and AIF to AIF)
* 807-4649
MIB Power/Blue LED/Pan Sw (used from Transformer and Fltr Rly to
MIB to Blue LED and Pan Sw)
* 807-4655 FV/DV Harness RTD Medium (used from RTD to ATO Board)
* 826-2569 FV/DV ATO/RTD Probe Kit
* 807-4553 ATO Power (used from Transformer to ATO Board)
* 807-4671
ATO Pump and JIB (used from ATO Board to Top-off Pump and JIB
Reset Switch)
* 807-4772
ATO Pump and JIB (used from ATO Board to Top-off Pump and JIB
Reset Switch) 4-5 Battery only
* 807-4555 ATO Yellow LED (used from ATO Board to Yellow LED)
* 807-4722
ATO Yellow LED (used from ATO Board to Yellow LED) 4-5 Battery
only
* 807-4573
Computer Locator Wire (used from Computer to Interface Board) See
wiring diagram 805-1734 for locator pin positions.
* 807-4552
Communications Terminator (used on Computer pin J6 and ATO
board pin J10 to terminate network)
807-4657 Jumper (used on 4 and 5 battery ATO board plug J5 pin 7 and 8)
* 106-9256SP Long Top-off Power (used between Component Box to ATO Box)
* 807-4760 Harness, LOV™ RTI-MIB connector
√ * 807-4660PK SMT Pin Service Repair Kit
√ * 230-2345 SMT Pin Extractor
* Not illustrated.
See page 1-14, 1-18, 1-27 and 1-36 for Pin Positions.
√ Recommended parts.
