Real Time Scopes Menu
Main Menu Real Time Scopes
Function Background Black
Real Time Scopes Display Window Both
Scopes & Audio Meters Lum Win Pos. Bottom Right
Video Lum Win Size 2x
Audio Vector Win Pos. Bottom Right
Marker Vector Win Size 2x
Alarm Lum Win Style IRE
OSD Color1 Red
GPI Divide1 -1
Color Management Color2 Green
System Divide2 100
System Status Color3 Yellow
Support Divide3 101
Color4 Red
Divide4 109
Color5 Red
Divide5 109
Color6 Red
Background
Select Background for Real Time Scopes windows. Select from Black, Translucent, and Transparent.
Display Window
Choose to display Luminance Window, Vectorscope Window, or Both.
Lum Win Pos., Vector Win Pos.
Set the position of the corresponding window. Selections include Bottom Right, Bottom Left, Top Right, and Top Left.
Lum Win Size, Vector Win Size
Set the size of the corresponding window. 1x or 2x.
Lum Win Style
Set the graticule mode of the Luminance Window. IRE, Voltage, 10bit Digital Levels, and HDR WFM.
Color & Divide
Color1 sets the color of levels under the Divide1 threshold.
Color2 sets the color of levels between the Divide1 and Divide2 thresholds.
Color3 sets the color of levels between the Divide2 and Divide3 thresholds and so on.
Finally, Color6 sets the color of any levels over the Divide5 threshold.
