Function Menu
Main Menu Function
Function F1 Realtime Scopes
Real Time Scopes F2 Scopes & Audio Meters 2
Scopes & Audio Meters F3 Scopes & Audio Meters 3
Video F4 Marker
Audio F5 Measurement (10Bit)
Marker F6 Fast Mode
Alarm Function Display Off
OSD
GPI
Color Management
System
System Status
Support
The Function Menu allows you to assign user selectable functions to any of the 6 function buttons (F1, F2, F3, F4, F5, & F6)
on the monitor keypad. Some monitor features listed as assignable options in the function menu are also selectable via the
embedded menus and are present simply to provide an option for faster, single button press access to the desired function.
Other features listed require a function key for activation, but may have associated customizable settings that can be found
in other menus.
Assigning Function Keys
To assign a function to a function key highlight one of the 6 Function lines and press ENTER. A list of assignable functions
will appear. Select the desired function with the UP and DOWN buttons and press ENTER to assign that function to the
corresponding function key. The Function Display option at the bottom of the Function Menu gives you the option to have
a temporary conrmation window appear on screen after a function key is pressed that will identify the function that was
turned on or off.
WARNING: Changing a function button
assignment does NOT automatically
turn an active function off. Make sure to
disable unwanted active functions before
changing function button assignments.
NOTE: Many features (Waveform,
Vector Scope, Audio Level
Meters, etc.) require a function
key in order to operate. Some
menus (such as the Scopes &
Audio Meters Menu) only set
your display preferences while a
corresponding function key must
be assigned to turn the feature
on and off. If you are having
trouble with a monitor feature
make sure you have assigned
the proper function key and any
corresponding menu settings.
