FSI DM160 - System Menu Configuration

© 2023 Flanders Scientic, Inc.
45
Return to Table of Contents
System Menu
Main Menu System
Function Load Prole
Real Time Scopes Save Prole
Scopes & Audio Meters Update Firmware
Video Keypad LED Normal
Audio Chroma/Bright/Contrast Unlock
Marker Luminance Interval On
Alarm Language English
OSD DHCP On
GPI IP Address 192.168.001.111
Color Management Subnet Mask 255.255.255.0
System Gateway 192.168.001.001
System Status RS422 Address 1
Support Baud Rate 9600
Parity None
Load Prole
Recall Saved Prole Settings. Highlight desired prole & press ENTER to activate the saved prole selection.
Save Prole
Saves all current monitor settings under a recallable prole by highlighting Prole number & pressing ENTER.
Update Firmware
When on you can simply plug your monitor into any compatible computer with the provided USB update cable and it will be
recognized as a USB mass storage device for transfer of new rmware and/or LUTs.
Use this to update rmware once your new rmware le has been loaded to the monitor.
Keypad LED
Allows you to turn off the LED lights on the Monitor’s Keypad. Select from Normal, All Off, and All On. In the default Normal
mode active keys will illuminate. In All Off mode, no keys will illuminate. In All On mode, all keys will stay illuminated and will
ash when activating or deactivating a function.
Chroma/Bright/Contrast
When set to Lock this option will lockout the Chroma, Brightness, & Contrast knobs to help prevent accidental adjustment.
Luminance Interval
The luminance interval is a power saving feature; It allows you to specify the amount of time without an active signal being
shown on the monitor that should be allowed to expire before the monitor’s backlight (if applicable) is turned off to reduce
the power consumption of the unit. When placed in the On position the monitor will not enter the power saving mode and
will keep the backlight on so long as the monitor is left on.
DHCP
Toggle DHCP On or Off. DHCP allows your monitor to receive an IP address from a DHCP server on your network.
IP Address, Subnet Mask, & Gateway
You can manually congure network settings when DHCP is disabled.
