Audio Menu
Main Menu Audio
Function SDI 1 Audio Digital CH1&2
Real Time Scopes SDI 2 Audio Digital CH1&2
Scopes & Audio Meters DVI-D Audio Digital CH1&2
Video DP Audio Digital CH1&2
Audio Audio Sync Signal Clock
Marker Audio Lockout Off
Alarm
OSD
GPI
Color Management
System
System Status
Support
SDI 1 Audio
Select which audio source is active (audible) when SDI 1 is the selected video input. You may select any single channel or
stereo pair of embedded audio (i.e. Digital Channel 1, 1&2, 3&4, etc.), Analog Audio (from minijack input), or No Sound. The
active stereo pair selected here will be the stereo pair shown when the Audio Phase Meter is activated on the SDI 1 Input.
SDI 2 Audio
Select which audio source is active (audible) when SDI 2 is the selected video input. You may select any single channel or
stereo pair of embedded audio (i.e. Digital Channel 1, 1&2, 3&4, etc.), Analog Audio (from minijack input), or No Sound. The
active stereo pair selected here will be the stereo pair shown when the Audio Phase Meter is activated on the SDI 2 Input.
DVI-D Audio
Allows you to select between Analog Audio input (via minijack connector) or No Sound when DVI-Digital is the selected
video input. You can also use the Channel 1 & 2 selection listed here for stereo HDMI audio support when using a HDMI or
Display Port to DVI cable.
DP Audio
Allows you to select between Analog Audio input (via minijack connector), No Sound, or Digital CH1 & 2 when Display Port
is the selected video input.
Audio Sync
Choose between Signal Clock or Internal Clock for Audio Sync. Some embedded audio sources may have a poor quality
signal clock that may lead to audio distortion. Switching to Internal Clock can help to eliminate or minimize such distortion.
Audio Lockout
When set to On, this feature will lock the Volume Knob, which retains the last used audio setting used. With Audio Lockout
On, no adjustments to volume will be possible.
