FSI DM160 - OSD Menu Options

© 2023 Flanders Scientic, Inc.
34
Return to Table of Contents
OSD Menu
Main Menu OSD
Function Status Display 5 s
Real Time Scopes Menu Position Top Right
Scopes & Audio Meters Status Position Top Left
Video Rotary Position Bottom
Audio Source ID Off
Marker Source ID Position Bottom
Alarm Source ID Character CAM1
OSD Time Code Off
GPI Time Code Size Small
Color Management Time Code Position Top
System Time Code Bg Translucent Black
System Status
Support
Status Display
Toggles settings for pop up window indicating resolution and frame rate of source when input button is pressed or a new
signal type is routed to monitor. Setting this option to Off turns the Status Display function completely off, setting to ‘5 s’
enables a 5 second on-screen status display when the input button is pressed or source format is changed, and setting to
On leaves the Status Display on-screen permanently.
Menu Position
Changes position of on-screen menu between three choices: Center, Top Left, or Top Right.
Status Position
Changes position of on-screen status display window. Select from Top Left, Top Right, Bottom Left, Bottom Right, or Center.
Rotary Position
Changes position of on-screen window indicating status of any rotary knob (Volume, Contrast, etc.) during adjustment.
Select from Top, Center, or Bottom.
Source ID
Allows you toggle source ID function on/off. The Source ID function can be used to set a manual on-screen label of up to 5
characters. This is often used to allow for the labeling of a monitor as PGM, PVM, CAM, etc. without using placards or tape.
Source ID Position
Changes position of on-screen Source ID function.
Source ID Character
Allows you to customize text for Source ID label using ENTER, UP, and DOWN buttons.
Time Code
Allows you to select whether to display Time Code on screen pulled from an HD/SD-SDI signal. Select between Off, LTC,
VITC 1, or VITC 2. Please note that Time Code cannot be displayed at the same time as some scopes and other on-screen
ancillary functions However, Time Code Display is compatible with simultaneous display of Markers and Real Time Scopes.
Time Code Size, Position, & Bg
Allows you to toggle between Large or Small Timecode Display, change the on-screen position of timecode, and select
translucent black or solid blue background colors.
