1-3.Change of upper/lower limit comparison value channel
This is the operation for switching channel of upper/lower limit comparison value being registered in advance.
[Example: Channel is switched from “0” to “5”]
１. 1. Push key ５
Ｆ
.
Letters marked with mesh is flashed.
In the case that letters other than “ ” are displayed,
push RESETkey.
2. Push ＳＥＴ／ＣＨＧkey
3. Push ７
ＨＩ
key
: This is the display of switching operation for co
mparison value channel.
4. Push ＳＥＴ／ＣＨＧkey
: This displays the channel that is now being used.
5. Input channel No. that is called up by using ten-key (0 to 9)
←Push ５
Ｆ
key.
6. Push ＳＥＴ／ＣＨＧkey
Upper/lower limit comparison value for channel 5 is displayed
← this shows upper limit comparison value.
← this shows lower limit comparison value.
7.Push RESET key
In these procedures, channel is switched.
(For the register of upper/lower limit comparison value, channel that is called up is displayed at first)
◎If RESETkey is pushed prior to pushing ＳＥＴ／ＣＨＧkey in the above 6, all previous operations are cancelled.
(Push one time before the stage of operation 4 or two times for the case after the pushing
ＳＥＴ／ＣＨＧkey in the operation 4)
Important: CP-2-003 (load-cell of 3kN rating loads is used) displays down to three decimal points.
