Fuji Electric FRENIC-Multi OPC-E1-DEV User Manual

29
(3) Control Supervisor object (Class 29 hex.)
This object monitors the current run command settings and the running status of the inverter, and configures the
running-related settings.
Instance Attribute Name Description Value (hex.) R/W Data size
0 01 Revision Revision number of Control
Supervisor object
0001 R Word
1 03 Run1 Run forward command 00: OFF
01: ON
R/W Byte
04 Run2 Run reverse command 00: OFF
01: ON
R/W Byte
05 NetCtrl Switching run command
source
00: Inverter
01: DeviceNet
R/W Byte
06 State Current inverter status 01: Inverter running
02: Inverter not ready
to run
03: Inverter ready to
run
04: Inverter running
05: During
deceleration
06: Stop due to
communication
broken
07: Tripped
R Byte
07 Running1 Running forward 00: Stopped/Running
reverse
01: Running forward
R Byte
08 Running2 Running reverse 00: Stopped/Running
forward
01: Running reverse
R Byte
09 Ready Inverter ready to run/Inverter
running
(Synchronized with State
above)
00: State = Value
except below
01: State = 03 to 05
R Byte
0A Faulted Tripped state 00: Not tripped
01: Tripped
R Byte
0B Warning Warning. Fixed at 0. 00: No warning R Byte
0C FaultRst Reset of tripped (alarm) state 00→01: Request for
reset
R/W Byte
0F CtrlFromNet Current run command source 00: Inverter
01: DeviceNet
R Byte
10 DNFaultMode Inverter reaction to DeviceNet
communications errors
Refer to Chapter 9. R/W Byte
