The table below lists the discharging capability and allowable average loss of the braking resistor.
These values depend upon the inverter and braking resistor models.
 External Braking Resistors㩷
Standard models
The thermal sensor relay mounted on the braking resistor acts as a thermal protector of the motor for
overheat, so assign an "Enable external alarm trip" terminal command THR to any of digital input
terminals [X1] to [X5], [FWD] and [REV] and connect that terminal and its common terminal to
braking resistor's terminals 2 and 1.
To protect the motor from overheat without using the thermal sensor relay mounted on the braking
resistor, configure the electronic thermal overload protection facility by setting F50 and F51 data to
the discharging capability and allowable average loss values listed below, respectively.
Braking
resistor
Continuous braking
(100% braking torque)
Intermittent braking
(Period: Less than 100s)
Power
supply
voltage
Inverter type
Type Qty.
Resistance
(:)
Discharging
capability
(kWs)
Braking
time
(s)
Allowable
average loss
(kW)
Duty
(%ED)
FRNF12E1ع-2U
FRNF25E1ع-2U
90 0.037 37
FRNF50E1ع-2U
9
0.044 22
FRN001E1ع-2U
DB0.75-2 100
17 0.068 18
FRN002E1ع-2U
34
45
0.075 10
FRN003E1ع-2U
DB2.2-2 40
33 30 0.077 7
FRN005E1ع-2U
DB3.7-2 33 37 0.093
FRN007E1ع-2U
DB5.5-2 20 55
20
0.138
FRN010E1ع-2U
DB7.5-2 15 37 0.188
FRN015E1ع-2U
DB11-2 10 55 0.275
Three-
phase
230 V
FRN020E1ع-2U
DB15-2 8.6 75
10
0.375
5
FRNF50E1ع-4U
9 0.044 22
FRN001E1ع-4U
DB0.75-4 200
17 0.068 18
FRN002E1ع-4U
34
45
0.075 10
FRN003E1ع-4U
DB2.2-4 160
33 30 0.077 7
FRN005E1ع-4U
DB3.7-4 130 37 0.093
FRN007E1ع-4U
DB5.5-4 80 55
20
0.138
FRN010E1ع-4U
DB7.5-4 60 38 0.188
FRN015E1ع-4U
DB11-4 40 55 0.275
Three-
phase
460 V
FRN020E1ع-4U
DB15-4 34.4 75
10
0.375
5
FRNF12E1ع-7U
FRNF25E1ع-7U
90 0.037 37
FRNF50E1ع-7U
9
0.044 22
FRN001E1ع-7U
DB0.75-2 100
17 0.068 18
FRN002E1ع-7U
34
45
0.075 10
Single-
phase
230 V
FRN003E1ع-7U
DB2.2-2
1
40
33 30 0.077 7
Note 1: A box () in the above table replaces S or E depending on the enclosure.㩷
Compact models
When using the compact models of braking resistor TK80W120: or TK80W100:, set F50 to "7" and
F51 to "0.033."
