5-41
Function code data
Active ON Active OFF
Terminal commands assigned Symbol
0 1000 SS1
1 1001 SS2
2 1002 SS4
3 1003
Select multi-frequency (0 to 15 steps)
SS8
4 1004 Select ACC/DEC time RT1
6 1006 Enable 3-wire operation HLD
7 1007 Coast to a stop BX
8 1008 Reset alarm RST
9 1009 Enable external alarm trip THR
10 1010 Ready for jogging JOG
11 1011 Select frequency command 2/1 Hz2/Hz1
12 1012 Select motor 2 / motor 1 M2/M1
13 Enable DC braking DCBRK
14 1014 Select torque limiter level TL2/TL1
17 1017 UP (Increase output frequency) UP
18 1018 DOWN (Decrease output frequency) DOWN
19 1019 Enable data change with keypad WE-KP
20 1020 Cancel PID control Hz/PID
21 1021 Switch normal/inverse operation IVS
24 1024
Enable communications link via RS-485 or field bus
(option)
LE
25 1025 Universal DI U-DI
26 1026 Enable auto search for idling motor speed at starting STM
27 1027 Switch to speed feedback control PG/Hz *
30 1030 Force to stop STOP
33 1033 Reset PID integral and differential components PID-RST
34 1034 Hold PID integral component PID-HLD
42 1042 Activate the limit switch at start point LS *
43 1043 Start/reset S/R *
44 1044 Switch to the serial pulse receiving mode SPRM *
45 1045 Enter the return mode RTN *
46 1046 Enable overload stop OLS *
98
Run forward
(Exclusively assigned to [FWD] and [REV] terminals
by E98 and E99)
FWD
99
Run reverse
(Exclusively assigned to [FWD] and [REV] terminals
by E98 and E99)
REV
Any negative logic (Active OFF) command cannot be assigned to the functions
marked with "
" in the "Active OFF" column.
The "Enable external alarm trip" and "Force to stop" are fail-safe terminal commands.
For example, when data = 9 in "Enable external alarm trip," "Active OFF" (alarm is
triggered when OFF); when data = 1009, "Active ON" (alarm is triggered when ON).
