-16-
Reference Guide Optional Units
4.
Insert a new staple case into the cartridge ( ) and
push the back side ( ).
5.
Insert the cartridge into the original position.
Hold the lever and lightly press it up until you hear a click.
6.
Close the cover.
Staple Jams
If paper is not being stapled or if staples are bent, follow the procedures mentioned in the following pages.
If the issue isn’t resolved even after the procedure, contact our customer support center or sales agency.
If the staple looks like any of the following images, contact our customer support center or sales agency.
Depending on the usage condition, such as the paper type, staples may be bent or bent staples may be
caught inside of the unit, causing paper jamming.
If you open the Staple Cartridge cover, be sure to remove all bent staples. Not removing bent staples may
cause staple jamming. Only open the Staple Cartridge cover when you are removing the jammed staples.
Please be very careful not to hurt your fingers, etc. when removing the jammed staple.
1
2
1
2
Paper is not stapled Staple is bent
One side of the staple is
loose
Staple is bent in
the wrong direction
Staple is collapsed
Staple is loose Staple is loose, and
the center sinks
To Next Page
