Fuji Xerox ApeosPort C2570 User Manual

-30-
Reference Guide Optional Units
v Finisher C
p.30 Device Components
p.33 Outputting Paper
p.33 Staple Cartridge
p.40 Waste Container
p.41 Paper Jams
In this guide, “Finisher C3” and “Finisher C3 with Booklet Maker” are generally referred to as “Finisher C”.
Device Components
*In case of Finisher with Booklet Maker
No. Name Description
1 Hole Punch Waste Container Punched pieces go in here.
2 Output Tray Paper is ejected.
3 Finisher Tray Side stitch paper is ejected.
4 Staple cartridge for side stitch This unit is used to replace staples for side stitch.
5 Booklet Tray* Saddle stitch paper is ejected.
6
Cover Open this door to clear paper jams, replace staples, remove jammed sta-
ples or dispose of cut pieces for punched holes.
7 Booklet Maker Unit This device is used to fold paper into two or staple folded paper.
8 Staple cartridges for saddle stitch* This unit is used to replace staples for saddle stitch. There are two.
78
6
4
1
5
3
2
