Fuji Xerox ApeosPort C2570 - Finisher A

-13-
iii Finisher A
iii Finisher A
p.13 Device Components
p.15 Outputting Paper
p.15 Staple Cartridge
p.18 Paper Jams
Device Components
No. Name Description
1 Center Tray Paper is ejected.
2 Extension Tray, guide wire This prevents the ejected paper from falling out.
3 Upper Cover Open this cover to clear paper jams.
4 Front Door Open this cover to replace staples or remove jammed staples.
5 Staple Cartridge This unit is used to replace staples.
5
2
1
4
3
