-18-
Reference Guide Optional Units
Paper Jams
If paper is jammed, the machine stops and an alarm sounds. A message also appears on the touch panel dis-
play. Follow the instructions displayed to remove the jammed paper.
Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the
machine, remove all the torn pieces making sure that none remain inside the machine.
When you have finished clearing the paper jam, printing is automatically resumed from the state before the
paper jam occurred. If a paper jam occurred during copying, tap on [Start]. Copying is resumed from the
state before the paper jam occurred.
Note
Clear the paper jams while the machine is on.
Upper Cover
1. Open the Upper Cover ( ) and remove the jammed
paper ( ).
2. Close the cover.
Finisher Connection
1. Open the Front Door.
2. Turn knob in the right direction ( ) and send the
jammed paper to the Center Tray side ( ).
1
2
1
2
1
2
1
2
