Machine Components
13
Product Overview
2
*1 Only available when Booklet Finisher D2 is installed.
*2 Only available when Folding unit (Z and C) is installed.
Note • Finisher and Booklet finisher D2 are optional. In text descriptions, finisher and booklet
finisher D2 may be called finisher.
35 Staple cartridge This cartridge contains staples. Remove this cartridge to replace staples
and clear staple jams.
36 Punch scrap container Collects the scraps from the puncher. Open throw away the scraps.
37
Tri-Fold output tray
*2
Receives copies when you select Tri-Fold In or Tri-Fold out.
38
Tri-Fold output tray button
*2
Press this button to open Tri-Fold output tray.
39 Left cover Open this cover to access the inside of the machine to clear paper jams.
No. Component Function
