2 Environment Settings
38
Environment Settings
2
Ethernet (Connectivity > Physical Connections)
Rated Speed
You can set the Ethernet port speed. You can select from Auto, 10 Mbps Half-Duplex,
10 Mbps Full-Duplex, 100 Mbps Half-Duplex or 100 Mbps Full-Duplex. (Default: Auto)
MAC Address
The machine's MAC address is displayed.
Apply button
You can apply changes by pressing this button.
Note • Reboot machine to enable new settings.
TCP/IP (Connectivity > Protocol)
IP Mode
You can set the IP operation mode. You can select from Dual Stack, IPv4 or IPv6. The
Dual Stack setting lets you use both IPv4 and IPv6 addresses. (Default: IPv4)
General
z
Protocol
[Enabled] is displayed.
z
Physical Connection
[Ethernet] is displayed.
z
Host Name
You can set the host name. You can enter up to 1 to 32 single-byte alphanumeric
characters or hyphens.
Note • Hyphens (-) cannot be used as the first or last character in the string.
z
IPv4
- IP Address Resolution:
You can set the method used to acquire the IP Address, Subnet Mask and
Gateway Address. You can select from STATIC, DHCP, BOOTP, RARP or DHCP/
Autonet for the address acquisition method. (Default: DHCP/Autonet)
- IP Address:
You can enter the IP address when [STATIC] is selected for [IP Address
Resolution].
- Subnet Mask:
You can enter the subnet mask when [STATIC] is selected for [IP Address
Resolution].
- Gateway Address:
You can enter the gateway address when [STATIC] is selected for
[IP Address Resolution].
z
IPv6
- Enable Manual Address:
You can check this checkbox to enter the IP address and gateway address
directly. (Default: Off)
- IP Address:
You can enter the IP address when the [Enable Manual Address] checkbox is
checked.
