2 Paper and Other Media
64
Paper and Other Media
2
Loading No.3 Standard Envelope, C5, or the Envelope Whose Width is less than 182 mm
1
Pull out the tray towards you until it stops.
Important • While the machine is processing a job, do not
pull the tray out that the job uses.
• To prevent paper jams or misloading, do not
load envelopes on any paper remaining in
the tray.
2 Remove any paper loaded in the tray.
3 Loosen the screw of the Post Card Kit attached
to the left side of the tray (1), and pull out the
Post Card Kit in the arrow direction (2).
4 Insert the small protrusions of the guide into
both the slot in the bottom right of the tray
and the screw hole on the front side of the tray
(1). Tighten the screw to secure the Post Card
Kit to the tray (2).
5 With the side to be copied or printed on facing
up, load approximately 10 to 30 envelopes in
the tray and align the bottom edges (not the
flap side) of the envelopes in the arrow
direction (1). Pinch the long-side paper guide
and slide it to the desired paper size (2).
When pulling out the paper tray, do it
slowly. If pulled out with too much
force, the tray can hit and injure your
knees.
To Next Page
