Replacing the Drum Cartridge
285
Replacing the Drum Cartridge
The drum cartridge is a customer replaceable unit. The machine will display a warning
message before the drum reaches the end of life. Order a replacement cartridge now
to insure continuous operation.
Removing the Old Drum Cartridge
1. Pull the front cover towards you
to open it.
2. Open the bypass tray, and then
open the Cover A while lifting up
the release lever.
3. Lift up the colored lever, and
slide the drum cartridge out until
you can lift the handle on top of
the cartridge.
4. Hold the handle and remove the
cartridge from the machine.
NOTE: When replacing the drum cartridge, make sure that the new cartridge is the
correct one specified for the machine.
A
D
C
