Working with the notebook
Removing an ExpressCard
You can stop the ExpressCard using the symbol in the task bar:
► Left-click on the icon.
► Select the ExpressCard you want to stop and remove.
► Press the Enter key.
Wait for the dialogue box which tells you that it is now safe to remove the ExpressCard.
1
2
► Press on the edge of the ExpressCard (1)
so that the ExpressCard jumps out of the
slot slightly.
► Pull the ExpressCard (2) out of the slot.
2
► Insert the placeholder for the ExpressCard
into the slot guide.
► Gently slide the placeholder for the
ExpressCard into the slot until you feel it
click into place.
10600718714, edition 1 29
