Working with the notebook
Integrated 56k modem
The integrated 56k modem supports all data communication applications, such as:
● Modem operation: High-speed downloads at up to 56,000 bit/s (V.9x). Downward-compatible to
V.34 modems.
● Fax operation: Transmitting and receiving at up to 14,400 bit/s
● Simple country adaptation with programme
The modem complies with the EU Directive 91/263/EEC (Telecommunications terminal equipment
directive) and has been checked in agreement with the guideline TBR-21.
The modem can be operated in the following countries:
Multifrequency (MFC) dialling
Belgium, Denmark, Germany, Finland, France, Greece, Great Britain, Holland, Ireland, Iceland, Italy,
Luxembourg, Norway, Austria, Portugal, Sweden, Switzerland and Spain.
Pulse dialling:
Belgium, France, Holland and Italy.
Also in: Poland, Slovenia, South Africa and Hungary.
Connecting notebook modem to telephone wall socket
4
3
1
2
► Connect the modem cable to the modem
port of the notebook (1).
► Plug the modem cable (2) into the country-
specific telephone adapter (3).
► Connect the modem cable to your
telephone wall socket (4).
Please note that the telephone line is busy and that you cannot use your telephone if the
modem cable is plugged into the telephone wall socket. Pull the modem cable out of the
telephone socket after you have finished your internet session or the fax mode and
reconnect the telephone cable.
i
10600718714, edition 1 37
