Connecting external devices
Ports
1
2
4
9
6
3
5
7
8
10
1 = Headphones port / Line out
2 = Microphone port / Line in
3 = FireWire port
4 = USB ports
5 = DC IN jack
6 = Modem port
7 = LAN port
8 = Monitor port
9 = S-Video out socket
10 = USB ports
Connecting an external monitor
An external monitor can be connected to the notebook.
► Switch off the notebook and the external
monitor.
► Connect the external monitor's data cable
directly to the notebook’s monitor port.
► First switch on the external monitor and
then the notebook.
Using the Fn + F4 key combination you can switch back and forth between the external monitor
and the notebook’s LCD screen.
You can display the same picture on the external monitor and the LCD screen simultaneously.
44 10600718714, edition 1
