Removing and installing components during servicing
Installing memory module
2
a
1
► Insert the memory module with the contacts
and the recess (a) facing the slot (1).
► Carefully push the memory module
downwards until it engages noticeably (2).
Mounting the cover
► Insert the cover in the groove (2) in the
direction of the arrow (1) and fold the cover
down (3).
2
2
3
1
► Fasten the cover with the 7 screws (1).
1
► Install the battery (see "Inserting the battery").
► Turn the notebook over and place it on a flat surface.
► Reconnect the cables that you disconnected before.
56 10600718714, edition 1
