5. CONTROL SYSTEM
INDOOR UNIT TYPE AND THE APPLICABLE CONTROL METHOD

Type Model
Indoor units
Compact
Cassette
Slim Duct
Wall mounted
Floor /
Ceiling
Floor
LJ LU LM LF
Central Remote
Controller
UT Y-DMM

M

*1

*1

*1

*1

*1

*1

*1

*1
Wired Remote
Controller
UT Y-RVN

M
  
*2

*3

*4
  
UT Y-RNN

M
  
*2

*3

*4
  
Wireless Remote
Controller
AR-RAH2E
- - - - -
 
-
AR-RAH1E

-

- - - -

AR-REA2E
- - -

- - - -
AR-REB1E
- - - -

- - -
IR Receiver Unit UT Y-LRH

M
-

- - - - - -
Simple Remote
Controller
UTY-RSN

M
  
*2

*3

*4
  

: Accessory,

: Optional, –: Not Applicable.
*1: Central remote controller is connected with Branch box.
*2: Optional Communication kit (UTY-XCBXZ1) is necessary for installation.
*3: Optional Communication kit (UTY-TWBXF) is necessary for installation.
*4: Optional Communication kit (UTY-XCBXZ2) is necessary for installation.
RESTRICTION OF WIRELESS REMOTE CONTROLLER

FUNCTIONS
The following indicates the restrictions of the wireless remote controller when used in
combination with other controllers to one indoor unit.
Model name
Wireless remote
controller functions
Wireless Remote
Controller only
Wireless Remote
Controller
+
Wired / Simple
Remote Controller
Wireless Remote
Controller
+
Central Remote
Controller
Wireless Remote
Controller
+
Wired / Simple
Remote Controller
+
Central Remote
Controller
AR-RAH1E

AR-RAH2E
UT Y-LRH

M
TIMER
   
SLEEP TIMER
   
10°C HEAT
   
AR-REA2E
TIMER
   
SLEEP TIMER
   
10°C HEAT
   
WEEKLY TIMER
   
POWERFUL
   
LOW NOISE
   
AR-REB1E
TIMER
   
SLEEP TIMER
   
10°C HEAT
   
POWERFUL
   
LOW NOISE
   

: This function is available.

: This function is not available.
- (05 - 04) -
CONTROL SYSTEM CONTROL SYSTEM

Fujitsu ASHG12LMCA Specifications

General

Type	Split system
Timer	Yes
Multi-split	-
Product color	White
Dehumidifying capacity	1.8 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	5300 W
Cooling capacity in watts (nominal)	3400 W
Cooling energy efficiency (EER, W/W)	3.5
Heating energy efficiency (COP, W/W)	3.92
Seasonal efficiency rating (cooling) (SEER)	7
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	4000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A++
Power consumption (cooling) (max)	970 W
Power consumption (heating) (max)	1020 W
Annual energy consumption (cooling)	170 kWh
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1225 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	203 mm
Indoor unit width	840 mm
Indoor unit height	268 mm
Indoor unit weight	8500 g
Indoor unit noise level (high speed)	43 dB
Outdoor unit depth	293 mm
Outdoor unit width	663 mm
Outdoor unit height	535 mm
Outdoor unit weight	26000 g
Outdoor unit noise level	50 dB
Airflow	750 m³/h
