6. SYSTEM DESIGN
MOUNTING POSITION1-4.
OUTDOOR UNIT

For the air conditioner to operate satisfactorily, install it as outlined in installation manual.
Outdoor unit mounting position

A position where satisfies the mounting space described in “3-3 Installation space".
A position where the unit can be installed horizontally.
A position with enough space for performing pipe work, service and maintenance.
Outdoor unit mounting limitation

A position that is not exposed to strong or seasonal winds.
A position where the blown air does not accumulate.
A position where there are no obstructions to the air near the inlet and outlet.
A position not exposed to radiation from other heat sources.
A position where the discharge air will not affect animals or plants.
A position where the noise and hot air will not disturb the neighbour.
A position with strong installation fixings, which can sufficiently bear the product weight.
A position that does not transmit noise or vibration.
A position where drain water discharge is not a problem.
A position where snow does not accumulate.
A position not easily affected by electrical noise.
A position out of reach of children.
A position where there is no danger of the generation, influx or accumulation of flammable gas.
A position that does not have a special environment such as large amounts of oil, vapor or 
sulfide gas.
- (06 - 09) -
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ASHG12LMCA Specifications

General

Type	Split system
Timer	Yes
Multi-split	-
Product color	White
Dehumidifying capacity	1.8 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	5300 W
Cooling capacity in watts (nominal)	3400 W
Cooling energy efficiency (EER, W/W)	3.5
Heating energy efficiency (COP, W/W)	3.92
Seasonal efficiency rating (cooling) (SEER)	7
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	4000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A++
Power consumption (cooling) (max)	970 W
Power consumption (heating) (max)	1020 W
Annual energy consumption (cooling)	170 kWh
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1225 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	203 mm
Indoor unit width	840 mm
Indoor unit height	268 mm
Indoor unit weight	8500 g
Indoor unit noise level (high speed)	43 dB
Outdoor unit depth	293 mm
Outdoor unit width	663 mm
Outdoor unit height	535 mm
Outdoor unit weight	26000 g
Outdoor unit noise level	50 dB
Airflow	750 m³/h
