5. CONTROL SYSTEM
SIMPLE REMOTE CONTROLLER2-3.
MODEL : UTY - RSN
 
M
FEATURES

User-friendly operation

Provides access to basic operations, such as Start / Stop, Fan speed, operation mode and 
room temperature setting.
A large Start / Stop button is provided in the centre of the remote controller unit for easy 
operation.
Following an error display, diagnostics can be carried out on the controller.
Background light

Background light enables easy operation in a darkened room.
Background light activates during all button operations which lasts 10 seconds 
in operating mode and 5 seconds in stop mode after a button is pressed.
Simple installation

Can be mounted on the European switch boxes (installation dimension: 60mm) or the JIS built-in box
(installation dimension: 83.5mm).
83.5mm
60mm
European
switch box
JIS built-in box
Easy operation.
Built-in background light function.
Easy installation with slim shape with no bulge in the back.
Error history.(Last 16 error codes can be accessed.)
Can be installed on switch boxes. (Applicable to European and 
other countries' standards)
- (05 - 31) -
CONTROL SYSTEM CONTROL SYSTEM

Fujitsu ASHG12LMCA Specifications

General

Type	Split system
Timer	Yes
Multi-split	-
Product color	White
Dehumidifying capacity	1.8 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	5300 W
Cooling capacity in watts (nominal)	3400 W
Cooling energy efficiency (EER, W/W)	3.5
Heating energy efficiency (COP, W/W)	3.92
Seasonal efficiency rating (cooling) (SEER)	7
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	4000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A++
Power consumption (cooling) (max)	970 W
Power consumption (heating) (max)	1020 W
Annual energy consumption (cooling)	170 kWh
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1225 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	203 mm
Indoor unit width	840 mm
Indoor unit height	268 mm
Indoor unit weight	8500 g
Indoor unit noise level (high speed)	43 dB
Outdoor unit depth	293 mm
Outdoor unit width	663 mm
Outdoor unit height	535 mm
Outdoor unit weight	26000 g
Outdoor unit noise level	50 dB
Airflow	750 m³/h
