Fujitsu ASHG12LMCA User Manual

6. SYSTEM DESIGN
WIRING DESIGN4.
ELECTRICAL WIRING4-1.
PRECAUTION FOR ELECTRICAL WIRING

Regulation on wire diameter and selecting circuit breaker size differ from locality.
Install in accordance with local rules and regulations.
Warning
Do not turn on the power until all installation work is complete.
Before starting work, check that power is not being supplied to the unit.
Connect the connection cable firmly to the terminal board. Imperfect installation may cause a fire.
Always fasten the outside covering of the connection cable with the cord clamp. (If the insulator is 
chafed, electric leakage may occur.)
Make sure to install Earth leakage breaker. Otherwise, it may cause electric shock or a fire.
Always connect the ground wire.
Never install a condenser for improving the power factor. (It will not improve the power factor and 
the condenser will become extremely hot.)
- (06 - 38) -
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ASHG12LMCA Specifications

General

Type	Split system
Timer	Yes
Multi-split	-
Product color	White
Dehumidifying capacity	1.8 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	5300 W
Cooling capacity in watts (nominal)	3400 W
Cooling energy efficiency (EER, W/W)	3.5
Heating energy efficiency (COP, W/W)	3.92
Seasonal efficiency rating (cooling) (SEER)	7
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	4000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A++
Power consumption (cooling) (max)	970 W
Power consumption (heating) (max)	1020 W
Annual energy consumption (cooling)	170 kWh
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1225 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	203 mm
Indoor unit width	840 mm
Indoor unit height	268 mm
Indoor unit weight	8500 g
Indoor unit noise level (high speed)	43 dB
Outdoor unit depth	293 mm
Outdoor unit width	663 mm
Outdoor unit height	535 mm
Outdoor unit weight	26000 g
Outdoor unit noise level	50 dB
Airflow	750 m³/h
