Fujitsu ASHG12LMCA User Manual

6. SYSTEM DESIGN
PRECAUTION

 eect the instaation ocation that eets the oowing reuireent and that is approed b the
customer.
 od and war air shoud reach the entire roo.
Installation height *1
D≦1000 mm
D
floor
*2
*1) Refer to Design & Technical manual for Air velocity distribution and Air temperature distribution during heating.
  the distance ro the ceiing is not adeuate it a cause idew stains on the wa or the ceiing. nsure to 
at least 150 mm away from any surface of the equipment.)
 o not insta the unit in the oowing areas
 he upper part o the icinit o roo entrance. t a cause condensation on the outet port.
 ear a wa surace. t a cause condensation on the wa during cooing.
 rea ed with inera oi or containing a arge aount o spashed oi or stea such as a itchen.
 he pace where it wi be eposed to direct sunight. r ese it a cause a change in coor.
 hen the instaation area is eposed to direct sunight tae easures to boc the ight such as
covering the grille surface with a sheet. Or else, it may cause a change in color.
 se an appropriate rie that is copatibe with the indoor unit.  not used with the correct
combination, it may cause condensation.
 Peror heat insuation and ed setting according the esign  echnica anua o ndoor unit.
Not installing as per the instructions may cause condensation.
- (06 - 145) -
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ASHG12LMCA Specifications

General

Type	Split system
Timer	Yes
Multi-split	-
Product color	White
Dehumidifying capacity	1.8 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	5300 W
Cooling capacity in watts (nominal)	3400 W
Cooling energy efficiency (EER, W/W)	3.5
Heating energy efficiency (COP, W/W)	3.92
Seasonal efficiency rating (cooling) (SEER)	7
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	4000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A++
Power consumption (cooling) (max)	970 W
Power consumption (heating) (max)	1020 W
Annual energy consumption (cooling)	170 kWh
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1225 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	203 mm
Indoor unit width	840 mm
Indoor unit height	268 mm
Indoor unit weight	8500 g
Indoor unit noise level (high speed)	43 dB
Outdoor unit depth	293 mm
Outdoor unit width	663 mm
Outdoor unit height	535 mm
Outdoor unit weight	26000 g
Outdoor unit noise level	50 dB
Airflow	750 m³/h
