Fujitsu D943 - Resource Table

Resource table Introduction
A26361-D943-Z120-14-7619 7
Resource table
possible IRQ Possible
Address
Possible
DMA
Keyboard IRQ1
Serial port COM2 / IrDA IRQ3,
IRQ4
02F8, 03F8
02E8, 03E8
Serial interface COM1 / Chip card
reader
IRQ4,
IRQ3
03F8, 02F8
03E8, 02E8
Floppy disk drive controller IRQ6 DMA2
Parallel interface LPT1 IRQ5, IRQ7 0278, 0378 DMA1, DMA3
RTC IRQ8
Audio controller
Joystick:
Base address:
MPU 401:
Adlib:
IRQ5, IRQ7, IRQ9,
IRQ10
0200-0207
0220-022F
0240-024F
0260-026F
0280-028F
0300-0301
0330-0331
0338-038B
DMA1, DMA3,
DMA5, DMA7
USB controller IRQ11
Mouse controller IRQ12
Numeric processor IRQ13
IDE controller 1 IRQ14
IDE controller 2 IRQ15
The interrupts, addresses and DMAs set in the factory are underlined.
„Possible IRQ“ = these interrupts can be used for your particular application
„Possible address“ = this address can be used for your particular application
„Possible DMA“ = this DMA can be used for your particular application
i
Please note that a resource cannot be used b
y
two a
pp
lications at the same
time.
