Advanced - advanced system configuration Settings in BIOS Setup
A26361-D943-Z120-14-7619 21
CacheMode-TransferMode
Requirement: The
Cache field must be set to Intern Only or Intern And Extern.
Cache Mode sets the mode in which the CPU uses the cache. The field is set to Write
Back
and can not be changed
In write-back mode the processor writes information to the cache and the
information is only written to the main memory if necessary. The information is
only written to the main memory if necessary. Main memory and cache contents
are not identical.
Cache System BIOS Area / Cache Video BIOS Area
TheCachefieldmustbesetto
Intern only or Intern and Extern.
Cache System BIOS Area and Cache Video BIOS Area lets you specify the BIOS that
should be mapped to the cache. Mapping the BIOS to the cache increases system
performance.
Enabled The specified BIOS is mapped to the cache (default entry).
Disabled The specified BIOS is not mapped to the cache.
Cache Memory Regions
TheCachefieldmustbesetto
Intern only or Intern and Extern.
Cache Memory Regions lets you specify the BIOS ROM areas that should be mapped
to the cache. Mapping the BIOS ROM areas to the cache increases system
performance.
Enabled The relevant ROM area is mapped to the cache.
Disabled The relevant ROM area is not mapped to the cache (default entry).
!
If
y
our ISA board uses a dual
p
orted RAM in the associated ROM area,
set the entr
y
to Disabled.
