PC Specialist's Handbook ErgoPro m664-series
Edition 1 - Release 1 - March 1998 Page 9-7
DIMM recommendations
DIMM
size
(MB)
Description Speed Voltage Type Clock
lines
Pins Module Kit code
16 2M*64 100 MHz 3.3V SDRAM 4 168 N/A N/A
32 4M*64 100 MHz 3.3V SDRAM 4 168 AF33852D PL060167
64 8M*64 100 MHz 3.3V SDRAM 4 168 AF33853D PL060168
128 16M*64 100 MHz 3.3V SDRAM 4 168 AF33854D PL060169
Explainations of the terms :
Speed: For SDRAM DIMMs this is the slowest clock speed that can be used (in MHz).
Module: Product code which is used to identify spares numbers and correct DIMM brands used with these
machines.
Kit code: This is the code that can be used when ordering memory upgrades. The kit includes one (1)
DIMM.
