Technical data
Technical data
Electrical data
Protection class: I
Rated voltage range 100 V – 240 V
Rated frequency
50Hz–60Hz
Max. rated current:
Model Power supply
Without monitor
socket Monitor socket
FUJITSU Desktop
ESPRIMO P9910
Power supply Platinum
680W (E645-V50)
7.5 – 3.5 A
–
Power supply Gold
280W (E643-V50)
3.5 – 1.5 A
–
FUJITSU Desktop
ESPRIMO P9010
FUJITSU Desktop
ESPRIMO P7010
FUJITSU Desktop
ESPRIMO P5010
Power supply Platinum
300W (E642-V20)
5.5 – 2.5 A 2.0 – 1.0 A
Dimensions
Width/depth/height without cable cover: 180 mm x 304 mm x 374 mm /
7,09 inch x 11,97 inch x 14,72 inch
Width/depth/height with cable cover (optional): 180 mm x 369 mm x 374 mm /
7,09 inch x 14,53 inch x 14,72 inch
Weight
Depending on the device variant and
configuration level
c.8kg/
17,64 lbs
Ambient conditions
Environment class 3K2
Environment class 2K2
DIN IEC 721 part 3-3
DIN IEC 721 part 3-2
Temperature
Operation (3K2) 10 °C .... 35 °C / 50 °F ... 95 °F
Transportation (2K2) -25 °C . ... 60 °C / -3 °F ... 140 °F
The formation of condensation is not permitted while the device is in operation !
Clearance required to ensure adequate ventilation:
without air vents
at least 10 mm /
0,39 inch
with air vents
at least 200 mm /
7,87 inch
44 Fujitsu
