− 16/83 −
4-6. Installing the Printer
Both horizontal installation (the paper exit is on the topside) and vertical
installation (the paper exit is on the front side) orientations are available.
In the case of vertical installation, attaching the optional splash-proof cover can
protect the printer from water.
The printer can also be fixed to the wall by using the optional wall-hanging
bracket.
Horizontal Installation
Vertical Installation
If the printer is installed vertically, stick the rubber feet (included in the package)
into the round indents on the printer rear cover.
Rubber Fee
Caution: Before sticking on the rubber feet, wipe off any dirt inside the
indents.
To Next Page
