11-3. LAN Interface
(1) LAN Interface Connector
Pin No. Signal Name Direction Signal Line Name
1
TX+ Output Output data
2 TX- Output Output data
3 RX+ Input Input data
4 N.C - -
5 N.C - -
6 RX- Input Input data
7 N.C - -
8 N.C - -
(2) LED
1
2
3
No. Meaning Description
1
10BASE-T Link
Lights up when the connection is recognized as
10BASE-T
2
100BASE-TX
Link
Lights up when the connection is recognized as
100BASE-TX
3 Status
Lights up for a period of time (50msec) when
packets are received
